Rosemount 3051 Coplanar Pressure Transmitter Technical Data and Selection Guide
Rosemount 3051 Coplanar Pressure Transmitter is supplied by SANTAN for industrial pipeline instrumentation, project procurement and maintenance replacement. This page summarizes model-specific data for preliminary engineering selection.
Verified Technical Specifications
| Measured variables | Differential, gauge and absolute pressure; flow and level by DP |
|---|---|
| Reference accuracy | Up to ±0.04% of span, range and option dependent |
| Rangedown | Up to 150:1 |
| Stability | Up to 10 years |
| Outputs | 4–20 mA/HART, WirelessHART, FOUNDATION Fieldbus, PROFIBUS and low-power options |
| Process interface | Coplanar flange with manifold and remote-seal options |
| Functional safety | SIL 2/3 capability by certified configuration |
Values depend on the complete order code and selected options. Confirm the latest manufacturer datasheet before final specification.
Selection Data Required
- Process medium, density and viscosity
- Minimum, normal and maximum range or flow
- Operating and design pressure and temperature
- Process connection, wetted materials and enclosure
- Output, protocol, power supply and hazardous-area approval
Industry Applications
Typical applications include oil and gas pipelines, chemical processing, power and steam systems, water treatment, storage tanks, compressor skids and machinery automation. Suitability must be checked against the actual process data.
Related Products and Solutions
Official Technical Reference
Rosemount official product documentation for 3051 Coplanar
Request a Quote
Send the complete model code, quantity and process data to sales@santanfluid.com. WhatsApp: +86 136 9022 3185 (China) or +62 823 1767 3750 (Indonesia). No online payment is required.
Standard Technical Specification Summary
Use these fields for preliminary selection. Final values depend on the complete manufacturer model code and selected options.
| Model | Rosemount 3051 Coplanar Pressure Transmitter |
|---|---|
| Measurement Range | 0…100 mbar up to 0…700 bar |
| Accuracy | Configuration-dependent; confirm the accuracy class and calibrated range. |
| Process Connection | ½ NPT / G½ / flange (DN/ANSI) |
| Output Signal | 4–20 mA HART / PROFIBUS-PA / FF / Modbus |
| Certifications | Confirm hazardous-area, functional-safety, sanitary, marine or custody-transfer approvals by model code. |
| Application Industries | Application-dependent; confirm medium, process conditions and industry requirements. |
